This topic provides a searchable list of all Maya hotkeys. You can also use the links at the bottomof this page to find groups of related hotkeys.
Tool Operations Return Complete current tool Insert Enter tool Edit mode Shift Q Select Tool, or with left mousebutton for Component marking menu Alt q Select Tool, or with left mousebutton for Polygon marking menu q Select Tool, or with left mousebutton for Selection Mask marking menu w Move Tool, or with left mousebutton for Move Tool marking menu e Rotate Tool, or with left mousebutton for Rotate Tool marking menu r Scale Tool, or with left mousebutton for Scale Tool marking menu Ctrl t Show universal manipulatortool t Show manipulator tool y Selects the last used tool that isnot one of Select, Move, Rotate, or Scale j Move, Rotate, Scale ToolSnapping (press and release) =, + Increase manipulator size
- Decrease manipulator size
Print
All Maya Hotkeys
d With left mouse button movepivot (Move Tool) Insert Switches between move pivotand move object (Move Tool)
Hotbox Display space (When pressed down) Showthe hotbox
Alt m Default Hotbox Style (Zonesand Menu Rows)
Displaying Objects (Show,Hide)
Ctrl h Display > Hide > Hide Selection Shift H Display > Show > ShowSelection
Ctrl+Shift H Display > Show > Show LastHidden
Alt h Display > Hide > HideUnselected Objects
Shift l Show > Isolate Select > ViewSelected (in the panel menus)
Display Settings 4 Shading > Wireframe 5 Shaded display 6 Shaded and Textured display 7 Lighting > Use All Lights 0 Default quality display setting 1 Rough quality display setting 2 Medium quality display setting 3 Smooth quality display setting
Alt v Turn Playback on or off Alt+Shift V Go to Min Frame k With middle mouse button forvirtual Time Slider mode (press and hold and scrubtimeline)
Tumble, Track, or Dolly Alt Left mouse button Tumble Tool (press andrelease)
Alt Middle mouse button Track Tool (press and release) Alt Right mouse button Dolly Tool (press and release)
2D Pan/Zoom + (^) Middle mouse button 2D Pan tool + Right mouse button 2D Zoom tool \ Enable/disable 2D Pan/Zoom.
Painting Operations Alt f Flood with the current value Alt a Turn Show Wireframe on oroff
Alt c Turn Color Feedback on or off Alt r Toggle Reflection on or off u With left mouse button forArtisan Paint Operation marking menu b Modify upper brush radius(press and release)
Shift B Modify lower brush radius(press and release)
Ctrl b Edit Paint Effects templatebrush settings
m Modify maximumdisplacement (Sculpt Surfaces and Sculpt Polygons Tool) n Modify paint value / Switch to pick color mode(press and release) 8 Open Paint Effects panel o With left mouse button for thePoly Brush Tool marking menu o With middle mouse button forPoly UV Tool marking menu
Snapping Operations c Snap to curves (press andrelease) x Snap to grids (press andrelease) v Snap to points (press andrelease) j Move, Rotate, Scale Toolsnapping (press and release)
Shift j Move, Rotate, Scale Toolrelative snapping (press and release)
Selecting Objects andComponents
F8 Select > Object/Component(Switch between object and component editing) F9 Select > Vertex F10 Select > Edge F11 Select > Face F12 Select > UV Ctrl i Select next intermediate object
Ctrl (or ) x Edit > Cut
Ctrl (or ) c Edit > Copy
Ctrl (or ) v Edit > Paste
Rendering Ctrl Left Render view next image Ctrl Right Render view previous image
Window and ViewOperations
Ctrl a Switches between AttributeEditor or Channel Box– displays the Attribute Editor ifneither is shown a Frame All in active panel, orwith left mouse button for History Operations markingmenu
Shift A Frame All in all views f Frame Selected in activepanel
Shift F Frame Selected in all views space (When tapped) Switchbetween the active window in multi-pane display and singlepane display
Ctrl space Switch between the standardview and full-screen view of the current panels ] Redo view change [ Undo view change Alt b Switch between a gradient,black, dark gray, or light gray background color. Shift { View previous layout
Shift } View next layout F1 Help > Maya Help
Moving SelectedObjects
Alt Up Move up one pixel Alt Down Move down one pixel Alt Left Move left one pixel Alt Right Move right one pixel
Pick Walk* Up Walk up current Down Walk down current Left Walk left in current Right Walk right in current *Based on selection, thearrow keys let you walk up the hierarchy (objectselected) or walk about the object’s components(component selected, including vertices, edgeloops, edge rings).
Modeling Operations 1 Default polygon mesh display (nosmoothing) 2 Cage + smooth polygon meshdisplay 3 Smooth polygon mesh display Ctrl h Display coarser subdivisionsurface level
Ctrl i Select/refine subdivision surfacecomponent
Noteon non-US English keyboards. Certain key combinations, such as those involving the ~ or ` keys, may not be accessible
Topics in this section Animation hotkeys Camera hotkeys Display hotkeys Edit operation hotkeys File operation hotkeys General tool hotkeys Interface hotkeys Modeling hotkeys Paint operation hotkeys Rendering hotkeys Selection hotkeys Snapping hotkeys Tool and action hotkeys Transformation hotkeys View hotkeys
