A set of practice questions and answers for the cisco 350-501 exam, covering topics related to implementing and operating cisco service provider network core technologies (spcor). The questions are designed to test the user's understanding of key concepts and technologies, including bgp, mpls, l2vpn, and snmpv3. Useful for individuals preparing for the 350-501 certification exam.
Typology: Exercises
1 / 11
This page cannot be seen from the preview
Don't miss anything!
2024 Latest leads4pass 350-501 PDF and VCE dumps Download
2024 Latest leads4pass 350-501 PDF and VCE dumps Download
Which BGP attribute is used first when determining the best path? A. origin B. AS path C. local preference D. weight Correct Answer: D
QUESTION 2 Refer to the exhibit.
A network engineer must implement SNMPv3 on a Cisco IOS XR router running BGP. The engineer configures SNMPv3 to use SHA for authentication and AES for privacy on the routers, which are in a different data center in the same exchange as other routers. The engineer must also verify the associated MIB view family name, storage type, and status. Which set of actions meets these requirements? A. Add configuration snmp-server user UserJustMe GrpMonitoring v3 auth sha AuthPass1 priv 3des 128 PrivPass2 and use show snmp interface to verify the configuration. B. Add configuration snmp-server user AuthUser group2 remote 10.1.1.1 v3 auth sha and use show snmp mib to verify the configuration. C. Add configuration snmp-server user AuthUser group2 remote 10.1.1.1 v3 auth sha and use show snmp engineid to verify the configuration. D. Add configuration snmp-server user UserJustMe GrpMonitoring v3 auth sha AuthPass1 priv aes 128 PrivPass2 and use show snmp view to verify the configuration. Correct Answer: D
Refer to the exhibit. A network engineer is implementing a standard customer route-policy on ASBR1 with these requirements:
2024 Latest leads4pass 350-501 PDF and VCE dumps Download
A. Option A B. Option B C. Option C D. Option D Correct Answer: D
2024 Latest leads4pass 350-501 PDF and VCE dumps Download
Which two steps must a service provider consider when adding multicast support to the existing MPLS L3VPN? (Choose two.) A. Using SSM for data MDT helps to minimize the number of group addresses needed in the core B. Using default MDT results in a reduction of multicast routing states in the core C. All PEs must be configured as RPs inside of each customer VRF to minimize impact of the RPF lookups D. Bandwidth may be wasted on PEs as a result of only using the default MDT E. Forwarding customer multicast traffic only via the default MDT optimizes PE utilization Correct Answer: BD Reference: https://www.nanog.org/meeting-archives/nanog44/presentations/Sunday/McBride_iptv_N44.pdf
QUESTION 5 What is the role of NSO? A. Provides public cloud services for customers that need Internet access. B. Controls the turn-up of a device. C. Provides network monitoring services for Layer 3 devices. D. Maintains data storage. Correct Answer: B
Refer to the exhibit.
An engineer is preparing to implement link aggregation configuration. Which statement about this configuration is true? A. The switch port negotiates an EtherChannel if it receives LACP packets from a connected peer running passive mode.
2024 Latest leads4pass 350-501 PDF and VCE dumps Download
A network engineer is configuring customer edge routers to finalize a L2VPN over MPLS deployment. Assume that the AToM L2VPN service that connects the two CEs is configured correctly on the service provider network. Which action causes the solution to fail? A. OSPF does not work with L2VPN services. B. The routing protocol network types are not compatible. C. A loopback with a /32 IP address has not been used. D. The xconnect statement has not been defined. Correct Answer: B
Refer to the exhibit.
2024 Latest leads4pass 350-501 PDF and VCE dumps Download
Router 1 and router 2 are running OSPF Area 0. The router logs on both routers show that the LDP link has flapped. Which configuration must the engineer apply to the two routers to implement session protection on the link? A. Router 1(config)# ip cef distributed Router 1(config)# mpls ldp session protection global Router 2(config)# ip cef distributed Router 2(config)# mpls ldp session protection global B. Router 1(config)# ip cef distributed Router 1(config)# interface gigabitethernet 0/0 Router 1(config-if)# ip address 192.168.1.1 255.255.255.0 Router 1(config)# mpls ldp session protection Router 2(config)# interface gigabitethernet 0/ Router 2(config-if)# ip address 192.168.1.2 255.255.255. Router 2(config)# mpls ldp session protection C. Router 1(config)# ip cef distributed Router 1(config)# interface gigabitethernet 0/0 Router 1(config-if)# ip address 192.168.1.1 255.255.255.255 Router 1(config-if)# exit Router 1(config)# mpls ldp session protection Router 2(config)# ip cef distributed Router 2(config)# interface gigabitethernet 0/ Router 2(config-if)# ip address 192.168.1.2 255.255.255. Router 2(config-if)# exit Router 2(config)# mpls ldp session protection D. Router 1(config)# ip cef distributed Router 1(config)# interface gigabitethernet 0/0 Router 1(config-if)# ip address 192.168.1.1 255.255.255.0 Router 1(config-if)# mpls label protocol ldp Router 1(config-if)# mpls ip Router 1(config-if)# exit Router 1(config)# mpls ldp session protection Router 2(config)# ip cef distributed Router 2(config)# interface gigabitethernet 0/ Router 2(config-if)# ip address 192.168.1.2 255.255.255. Router 2(config-if)# mpls label protocol ldp Router 2(config-if)# mpls ip
2024 Latest leads4pass 350-501 PDF and VCE dumps Download
Correct Answer: C
Refer to the exhibit. A global company plans to implement BGP at its newest location to provide connectivity to other offices. The global infrastructure of the company is a multivendor environment. An engineer must review the BGP core configurations at headquarters to determine if they can be repurposed at the new location. The engineer copied this JSON script for review. What is the effect of the script? A. It configures BGP on the device and inserts 192.168.1.0/24 into the BGP table using the origin AS 65514. B. It configures a VRF named cisconode1 and a BGP instance using the VPNv4 address family. C. It configures BGP with neighbor 192.168.1.2 residing in AS 65514. D. It sets the BGP router-ID to 192.168.1.2 and sets the AS of the router to 65514. Correct Answer: C
Refer to the exhibit.
2024 Latest leads4pass 350-501 PDF and VCE dumps Download
An engineer at a new ISP must configure many Cisco devices in the data center. To make the process more efficient, the engineer decides to automate the task with a REST API. Which action does this JSON script automate? A. Configure the IP address for the existing loopback interface. B. Configure a physical interface on the router with an IP address and then create a loopback interface. C. Configure a physical interface on the router with an IP address. D. Delete the existing loopback Interface and replace it with a new loopback interface. Correct Answer: A
