Digital Fountains:

Applications and Related Issues

Goals

  • Explain the digital fountain paradigm for network

communication.

  • Examine related advances in coding.
  • Summarize work on applications.
  • Speculate on what comes next.

How Do We Build

a Digital Fountain?

  • We can construct (approximate) digital

fountains using erasure codes.

  • Including Reed-Solomon, Tornado, LT, fountain codes.
  • Generally, we only come close to the ideal

of the paradigm.

  • Streams not truly infinite; encoding or decoding times; coding overhead.

History

  • Reed-Solomon codes
  • Tornado Codes
  • Luby Transform
  • Rateless/Raptor codes

Applications

  • Reliable multicast
  • Parallel downloads
  • Long-distance transmission (avoiding TCP)
  • One-to-many TCP
  • Content distribution on overlay networks
  • Streaming video

Reliable Multicast

  • Many potential problems when multicasting

to large audience.

  • Feedback explosion of lost packets.
  • Start time heterogeneity.
  • Loss/bandwidth heterogeneity.
  • A digital fountain solves these problems.
  • Each user gets what they can, and stops when they have enough.

Point-to-Point Data Transmission

  • TCP has problems over long-distance connections.
    • Packets must be acknowledged to increase sending window (packets in flight).
    • Long round-trip time leads to slow acks, bounding transmission window.
    • Any loss increases the problem.
  • Using digital fountain + TCP-friendly congestion control can greatly speed up connections.
  • Separates the “what you send” from “how much” you send. - Do not need to buffer for retransmission.

One-to-Many TCP

  • Setting: Web server with popular files, may have many open connections serving same file. - Problem: has to have a separate buffer, state for each connection to handle retransmissions. - Limits number of connections per server.
  • Instead, use a digital fountain to generate packets useful for all connections for that file.
  • Separates the “what you send” from “how much” you send. - Do not need to buffer for retransmission.
  • Keeps TCP semantics, congestion control.

Video Streaming

  • For “near-real-time” video:
    • Latency issue.
  • Solution: break into smaller blocks, and encode

over these blocks.

  • Equal-size blocks.
  • Blocks increases in size geometrically, for only logarithmically many blocks.
  • Engineering to get right latency, ensure blocks

arrive on time for display.

Other Applications

  • Other possible applications outside of

networking

  • Storage systems
  • Digital fountain codes for errors
  • Others???

Patent Issues

  • Several patents / patents pending on irregular LDPC codes, LT codes, Raptor codes by Digital Fountain, Inc.
  • Supposition: the theory/practice of digital fountains was greatly developed by the company and its employees.
  • Supposition: but this stifles external innovation.
    • Potential threat of being sued.
    • Potential lack of commercial outlet for research.
  • Suggestion: need unpatented alternative that approximate a digital fountain. - There is work going on in this area, but more is needed to keep up with recent developments in rateless codes.

Perceived Complexity

  • Digital fountains are now not that hard…
  • …but networking people do not want to deal with developing codes.
  • A research need:
    • A publicly available, easy to use, reasonably good black box digital fountain implementation that can be plugged in to research prototypes.
  • Issue: patents.
    • Legal risk suggests such a black box would need to be based on unpatented codes.

Conclusions

  • Digital fountain paradigm and enabling codes have significant potential. - Many proposed applications. - More to come.
  • Applications helped push forward the technology.
    • Codes with better and better properties.
  • Challenge in moving from a “technology” to use in the real-world. - A simple, easy-to-use implementation based on non- proprietary might spur research community. - Need more potential killer apps to spur business community.
