ABSTRACT
A Linked-plane Obstacle-set Algorithm for Modeling Broad Muscle Paths:
Application to the Deltoid Muscle
Bo Xu, M. S. B. M. E.
Mentor: Brian A. Garner, Ph. D.
Computer modeling is commonly used to simulate muscle paths for the study of
human biomechanics. Because some muscles, such as broad muscles, have complex
morphology, modeling the paths of these muscles can be challenging.
The aim of this study is to develop a new algorithm that quickly and realistically
models the wrapping paths of broad muscles. The algorithm treats the muscle as a
series of elastic bands wrapping around sphere-shaped obstacles. Each band is
constrained to lie in its own plane and wrap around its own sphere. Each band plane
forms a given angle with respect to the adjacent band plane, with the first band plane
forming an optimized angle with respect to a fixed reference plane. The optimization
seeks to minimize the sum total of all band lengths. The new algorithm accounts for
tissue connectivity between muscle fibers in broad muscles, and can reproduce realistic
muscle moment arm simulations.
